BUSBAR RISER

Busbar riser is designed according to structure of building, it required less space compare to cable.

Busbar Riser Systems - RR Global

Product Range

TECHNICAL DATA

CatNo SWEEP Title
Compliance IEC 61439 - 6 & 1 Busbar Riser
Certification Authority ASTA Busbar Riser
Busbar Arrangement Sandwich Construction Busbar Riser
Busbar Conductors Copper & Aluminum Busbar Riser
Busduct Ratings 800A~6300A (Copper) / 800A- 5000A (Aluminum) Busbar Riser
Busbar Configuration Aluminium TPN & TPNE Busbar Riser
Busbar Configuration Copper TP & TPN Busbar Riser
Busbar Configuration Copper TPN + 100%E Busbar Riser
Busbar Configuration Copper TPN + 50%E Busbar Riser
Busbar Configuration Copper TP + DN + 100%E Busbar Riser
Rated Operational Voltage (Ue) 1000V AC Busbar Riser
Rated Insulation Voltage (Ui) 1000V AC Busbar Riser
Rated Dielectric Voltage 3.5 kV r.m.s 1 minute Busbar Riser
Rated Impulse Voltage 12 kV (1.2/50µsec) Busbar Riser
Rated Frequency 50 /60 HZ Busbar Riser
Degree of Protection Feeder- IP65 as standard & IP67 on request Busbar Riser
Enclosure Material Extruded Aluminum (Thickness 3.0 mm) Busbar Riser
Enclosure Finish Epoxy polyester powder coated – RAL7035 Busbar Riser
Busbar Material Copper / Aluminum Busbar Riser
Conductors Mill Finish / Tin or Silver Plated Busbar Riser
Integral Earth (PE) Aluminum Housing Busbar Riser
Busbar Insulation Polyester + Nomex Busbar Riser
Tap Off rating 32~800 A Busbar Riser
Tap Off Contacts Plug in type Busbar Riser
Joint UNIBLOCK with tamper proof shear off nuts Busbar Riser
